Heat Exchanger Tube Size Weight Chart in kg, mm, PDF
Heat Exchanger Tube Manufacturers make these Tubes in various dimensions depending on the application. However, most Tube have an outer diameter of between 3/4" and 2". The length can also vary but is typically between 12" and 36".
| Outside Diamete | Birmingham Wire Gauge (BWG) | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 20 | 18 | 16 | 15 | 14 | 13 | 12 | 11 | 10 | |||
| In | Mm | ||||||||||
| (0.889 Mm) | (1.245 Mm) | (1.651 Mm) | (1.829 Mm) | (2.108 Mm) | (2.413 Mm) | (2.769 Mm) | (3.048 Mm) | (3.403 Mm) | |||
| Weight, Kg/M (Average Wall ) | |||||||||||
| 1/4 | 0.250 | 6.350 | 0.12 | 0.16 | 0.19 | – | – | – | – | – | – |
| 5/16 | 0.313 | 7.950 | 0.15 | 0.21 | 0.25 | 0.28 | – | – | – | – | – |
| 3/8 | 0.375 | 9.525 | 0.19 | 0.25 | 0.31 | 0.34 | 0.39 | – | – | – | – |
| 1/2 | 0.500 | 12.700 | 0.25 | 0.34 | 0.45 | 0.49 | 0.55 | 0.61 | 0.68 | 0.72 | – |
| 5/8 | 0.625 | 15.875 | 0.33 | 0.45 | 0.58 | 0.64 | 0.71 | 0.80 | 0.89 | 0.97 | – |
| 3/4 | 0.750 | 19.050 | 0.40 | 0.55 | 0.72 | 0.77 | 0.88 | 0.98 | 1.12 | 1.20 | 1.31 |
| 7/8 | 0.875 | 22.225 | 0.46 | 0.64 | 0.83 | 0.92 | 1.04 | 1.18 | 1.32 | 1.44 | 1.58 |
| 1 | 1.000 | 25.400 | 0.54 | 0.74 | 0.97 | 1.06 | 1.21 | 1.37 | 1.55 | 1.68 | 1.92 |
| 1 1/8 | 1.125 | 28.575 | 0.61 | 0.83 | 1.10 | 1.21 | 1.37 | 1.56 | 1.76 | 1.92 | 2.11 |
| 1 1/4 | 1.250 | 31.750 | 0.68 | 0.94 | 1.23 | 1.35 | 1.53 | 1.76 | 1.96 | 2.16 | 2.40 |
| 1 3/8 | 1.375 | 34.925 | 0.74 | 1.03 | 1.35 | 1.49 | 1.70 | 1.93 | 2.19 | 2.40 | 2.65 |
| 1 1/2 | 1.500 | 38.100 | 0.82 | 1.13 | 1.49 | 1.64 | 1.87 | 2.17 | 2.40 | 2.63 | 2.92 |
| 1 3/4 | 1.750 | 44.450 | 0.97 | 1.32 | 1.74 | 1.92 | 2.20 | 2.50 | 2.84 | 3.10 | 3.44 |
| 2 | 2.000 | 50.800 | – | 1.52 | 1.99 | 2.20 | 2.53 | 2.89 | 3.27 | 3.59 | 3.97 |
| 2 1/4 | 2.250 | 57.150 | – | 1.73 | 2.26 | 2.48 | 2.87 | 3.26 | 3.70 | 4.06 | 4.51 |
| 2 3/8 | 2.375 | 60.325 | – | 1.81 | 2.38 | 2.63 | 3.02 | 3.44 | 3.93 | 4.30 | 4.78 |
| 2 1/2 | 2.500 | 63.500 | – | 1.91 | 2.52 | 2.78 | 3.18 | 3.66 | 4.14 | 4.54 | 5.04 |
| 2 7/8 | 2.875 | 73.025 | – | 2.20 | 2.90 | 3.20 | 3.68 | 4.20 | 4.79 | 5.25 | 5.83 |
| 3 | 3.000 | 76.200 | – | 2.31 | 3.04 | 3.35 | 3.85 | 4.39 | 5.00 | 5.49 | 6.10 |
| 3 1/2 | 3.500 | 88.900 | – | 2.69 | 3.56 | 3.93 | 4.51 | 5.15 | 5.86 | 6.44 | 7.17 |
| 4 | 4.000 | 101.60 | – | – | 4.11 | 4.54 | 5.21 | 5.95 | 6.80 | 7.47 | 8.30 |
