Zion Tubes & Alloys is a notable Bright Annealed Stainless Steel Tube Manufacturer in India. Being the top most Bright Annealed Stainless Steel Tube Supplier, a wide range of goods are supplied from our warehouse, including Bright Annealed Tubing, Stainless Steel Annealed Tubing, and Seamless Brilliant Annealed Tubes. If you have any query related to our products feel free to reach out.
Bright Annealed Stainless Steel Tube Manufacturer ensures that they have a thorough grasp of customer requirements in order to produce high-quality goods that satisfy industry standards.
Zion Tubes & Alloys is a major Bright Annealed Stainless Steel Tube Supplier. Bright Annealed Stainless Steel Tubes are utilised in a variety of industries and are made with the process of modernised technology and high-quality raw materials. Our goods are available in a wide range of thicknesses, specifications, grades, and measurements.
Bright Annealed Stainless Steel Tube Manufacturer in India, make these tubes in different sizes and shapes. The dimensions of a standard stainless steel bright annealed tube are as follows:
Stainless Steel Bright Annealed Tube | Specifications |
Standards: | ASTM A269 / ASME SA269 |
Dimensions: | ASTM,AISI,ASME |
Lenght: | 6-24M. |
Thickness : | 0.5 ~ 70mm |
Grades : | 301, 304, 304L,304LN,304N ,305,309,309S,310,310S,316,316L.316LN, 316N,316Ti,317,317L,321,321H,347,347H,904L |
As a top Bright Annealed Stainless Steel Tube Supplier, one of the most significant advantages of employing stainless steel bright annealed tubing is its higher strength when compared to other materials such as aluminium or copper. There are several varieties of stainless steel tubes on the market.
According to Bright Annealed Stainless Steel Tube Manufacturers, the chemical composition of these tubing include a combination of Carbon, Nickel, Silicon and Chromium.
Grade | C | Ni | Si | N | S | Mn | P | Cr | Mo | |
SS 304 | min. | - | 8.0 | - | - | - | - | - | 18.0 | - |
max. | 0.08 | 10.5 | 0.75 | 0.10 | 0.030 | 2.0 | 0.045 | 20.0 |
The mechanical qualities of stainless steel bright tubes vary depending on the Bright Annealed Stainless Steel Tube Manufacturers work and the grade and thickness of the tube. The following are the most frequent mechanical properties:
Grade | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness | |
Rockwell B (HR B) max | Brinell (HB) max | ||||
SS 304 | 515 | 40 | 205 | 92 | 201 |
In accordance to Bright Annealed Stainless Steel Tube Manufacturers, the most common grades of ss bright tubing are 304 and 316L. 304 grade has 20% chromium and 10% nickelalloys with minimal amounts of carbon (0.08%). Various grades have different compositions as follows
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
SS 304 | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18-09 | X5CrNi18-10 |
SS 304L | 1.4306 / 1.4307 | S30403 | SUS 304L | 3304S11 | 03Х18Н11 | Z3CN18-10 | X2CrNi18-9 / X2CrNi19-11 |
SS 310 | 1.4841 | S31000 | SUS 310 | 310S24 | 20Ch25N20S2 | - | X15CrNi25-20 |
SS 310S | 1.4845 | S31008 | SUS 310S | 310S16 | 20Ch23N18 | - | X8CrNi25-21 |
SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | - | Z7CND17-11-02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17-11-02 / Z3CND18-14-03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
SS 316Ti | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17-123 | X6CrNiMoTi17-12-2 |
SS 317 | 1.4449 | S31700 | SUS 317 | - | - | - | - |
SS 317L | 1.4438 | S31703 | SUS 317L | - | - | - | X2CrNiMo18-15-4 |
SS 321 | 1.4541 | S32100 | SUS 321 | - | - | - | X6CrNiTi18-10 |
SS 321H | 1.4878 | S32109 | SUS 321H | - | - | - | X12CrNiTi18-9 |
SS 347 | 1.4550 | S34700 | SUS 347 | - | 08Ch18N12B | - | X6CrNiNb18-10 |
SS 347H | 1.4961 | S34709 | SUS 347H | - | - | - | X6CrNiNb18-12 |
SS 446 | 1.4762 / 3 | S44600 | - | - | - | - | - |
SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | - | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
SMO 254 | 1.4547 | S31254 | - | - | - | - | X1CrNiMoCuN20-18-7 |
MM | INCH | SCH 5 | SCH 10 | SCH 40 |
15 | 1/2" | 175 | 222 | 262 |
20 | 3/4" | 211 | 275 | 341 |
25 | 1" | 262 | 421 | 497 |
32 | 1.1/4" | 334 | 541 | 642 |
40 | 1.1/2" | 385 | 624 | 820 |
50 | 2" | 483 | 798 | 1084 |
65 | 2.1/2" | 778 | 1145 | 1855 |
80 | 3" | 948 | 1406 | 2289 |
100 | 4" | 1225 | 1821 | 3265 |
125 | 5" | 1969 | 2471 | 4719 |
150 | 6" | 2352 | 2925 | 5578 |
200 | 8" | 3072 | 4158 | 8658 |
250 | 10" | 5005 | 6440 | 11277 |
300 | 12" | 6660 | 7616 | 15075 |
350 | 14" | 7865 | 9094 | 18384 |
Time to make your inquiry and ask any questions regarding Bright Annealed Stainless Steel Tube / Bright Annealed Stainless Steel Tubing. We are devoted to meeting quality standards and delivering our products on schedule time. Call us +91 98195 64323 or mail us info@ziontubes.com our sales engineers will provide you with exact sizes available in stock and confirm delivery schedule.
Zion Tubes & Alloys stand for quality Bright Annealed Tube, and our brand name is one that clients recognise which makes us a leading Bright Annealed Stainless Steel Tube Supplier in India. Bright Annealed Tube have been provided to a range of sites and enterprises throughout India. Send us your enquiries via email – info@ziontubes.com or whatsapp us your requirements .
Product supplied | City |
---|---|
Bright Annealed Tube in Oil Plant | Rajkot, Gujarat |
All types of Bright Annealed Tube supply | Ahmedabad, Surat |
Stainless Steel Bright Annealed Tube | Delhi, Mumbai |
Mild Steel Bright Annealed Tube | Chennai, Kolkata, Pune |
Zion Tubes & Alloys is the leading Bright Annealed Stainless Steel Tube Manufacturer & Supplier in India.
Zion Tubes & Alloys is a leading Bright Annealed Stainless Steel Tube Manufacturer & Bright Annealed Stainless Steel Tube Supplier in India, offering a diverse selection of high-quality tube used in a variety of commercial and industrial applications. We have a huge inventory in various sizes, shapes, and materials as a trusted Bright Annealed Stainless Steel Tubing Supplier.
Zion Tubes & Alloys is not only a top Bright Annealed Stainless Steel Tube Exporter in India but also a top Bright Annealed Stainless Steel Tube Supplier with quality auditors who perform quality checks in accordance with industry standards. As a trusted Bright Annealed Stainless Steel Tube Stockist, we maintain a large inventory of tubes to fulfill the diverse needs of our customers in a timely and efficient manner.
